Supports 16 CH TVI / AHD /CVI 4K / 5MP / 4MP / 1080P / 720P / WD1 video input
Supports 8 CH 5MP / 4MP / 3MP / 1080P / 960P / 720P IP video input
8CH analog video input can be switched to 8CH IP video input
Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
Multi-mode recording: manual / timed / sensor /motion / AI recording
Playback : 16 CH simultaneously playback
Search: time slice, time, event, tag search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Remote control via Web or CMS : preview, playback, backup, PTZ and configuration
Authorization management, log review and device status review
Support 1080P output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Andriod OS
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Model | TD-2116NS-HC-H | |
System | OS | Embedded Linux |
Video | Analog Video Input | BNC × 16 |
BNC interface (1.0Vp-p; 75Ω) | ||
TVI/AHD/CVI:4K@15fps/5MP@20fps; 4MP/1080P/720P @30fps; Supports CVBS | ||
IP Video Input | 8CH (up to 16CH) | |
Up to 5MP@30fps | ||
Total Input | 24CH | |
Output | HDMITM × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |
VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 | ||
BNC × 1 : CVBS ( used as the main or spot output ) | ||
Compression | H.264/H.265/H.265+ | |
Multi-screen Display | 1 /4/6/8/9/13/16/25 | |
Audio | Input | RCA × 1 |
Output | RCA × 1 (linear, 600Ω) | |
Two-way audio | Take up channel one audio input | |
Compression | G.711(U/A) | |
Record | Resolution | 8MP Lite / 5MP Lite/ 4MP Lite/ 1080P/ 1080P Lite/ 720P/ WD1 |
Frame Rate | Analog Channel: 8MP Lite: 8fps; 5MP Lite:12fps; 4MP Lite/1080P:12fps(PAL)/ | |
Bit Rate | 32Kbps ~ 5Mbps | |
Mode | Manual, timer, motion, smart event | |
Playback | Playback | 16 CH |
Search | Time slice / time / event / tag search | |
Smart Search | Highlight colors to display the camera record in a certain period of time, | |
Function | Play, pause, FF, FB, digital zoom, etc. | |
Alarm | Mode | Manual, motion, exception, smart event |
Input | No | |
Output | No | |
AI Function | Smart Motion Detection Performance | 16CH |
Perimeter Protection Performance | 1CH | |
Network | Interface | RJ 45 100Mbps × 1 |
Protocol | TCP / IP, HTTP, HTTPS, 802.1x, DHCP, DDNS, FTP, RTP, RTSP, RTCP, NTP, UPnP, | |
Incoming Bandwidth | 32Mbps (max. 64 Mbps) | |
Outgoing Bandwidth | 80Mbps | |
Client Connection | Max. 10 users access | |
Mobile Device | OS | iOS, Andriod |
Storage | HDD | SATA × 1, up to 10TB |
Backup | Local Backup | U disk, USB mobile HDD |
Network Backup | Yes | |
Port | RS 485 | RS 485 × 1 (half-duplex) |
USB | USB 2.0 × 2 ( in the rear panel ) | |
Remote Controller | Optional | |
Others | Power Supply | DC12V / 3A |
Consumption | ≤10W(without HDD ) | |
Dimensions(mm) | 255× 234× 42 ( W × D × H ) | |
Working Environment | -10~50°C, 10%~90% (humidity) | |
Certificate | CE, FCC | |
Environmental Protection | Comply with Directive EU RoHS, WEEE, REACH | |
