System

OS

Embedded Linux

Video

Network Input

4 CH IPC input

8CH IPC input

Network Input Resolution

8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF

Output

HDMI^TM × 1: 3840×2160@30fps/1920×1080/1280×1024/1024×768
VGA: 1920×1080/1280×1024/1024× 768
HDMI^TM and VGA output the same video source

Compression

H.265S / H.265+ /H.265 /H.264

Multi-screen Display

 1/4

1 / 4 / 6 / 8 / 9

Audio

Network Input

4 CH IPC audio input

8 CH IPC audio input

Local Input

No

Local Output

No (HDMI^TM supports the audio output)

Compression

G.711(U/A)

Record

Resolution

8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF

Frame Rate

30fps/25fps(NTSC/PAL)

Playback

Simultaneous Playback

Max. 4 CH

Max. 8 CH

Search

Time slice / time / event / tag /smart search

Smart Search

Highlighted color to display the camera record in a certain period of time,
different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Decoding Capability

Live View/ Playback

1CH 8MP;
4CH 1080P

Alarm

Type

Manual, sensor, motion, exception, smart events, etc.

Input

No

Output

No

Triggering

Record, snapshot, buzzer, preset, e-mail, etc.

Network

Interface

RJ 45 100Mbps × 1

Protocol

TCP / IP, HTTP, HTTPS, 802.1, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP,
SMTP, IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP, ONVIF, etc.

Incoming/ Outgoing Bandwidth

40/64 (Mbps)

64/64 (Mbps)

*When the AI function of the IPC is enabled, the actual incoming
bandwidth(max.bitrate) is more than the set value in the NVR.

Client Connection

Max. 64 users access

Face

Face Detection Performance (AI by IPC)

4 CH

8 CH

Face Detection Performance (AI by Device)

No

Face Match Performance

No

Statistical Graph of Information

Bar graph

Statistical Mode of Information

Statistics by day, week, month, quarter as well as customized time period

Perimeter Protection

Human/Vehicle Classification (AI by IPC)

4 CH

8 CH

Human/Vehicle Classification (AI by Device)

No

Video Metadata

Human/Vehicle Attribute Analysis (AI by IPC)

Yes

Other Functions

Fisheye

Supports fisheye dewarping via Web Client and mobile APP

Plate Detection (AI by IPC)

Yes

Mobile Device

OS

iOS, Andriod

Storage

HDD Interface

SATA3.0 × 1, max 10T

Backup

Local Backup

USB flash drive

Network Backup

Yes

Port

USB

USB 2.0 × 2

Remote Controller

No

PoE

PoE Ports

100M RJ45 × 4

100M RJ45 × 8

Standards

IEEE802.3AF/AT

Output Power

≤ 40W

≤ 72W

Others

Power Supply

DC 48V/1.25A

DC 48V/1.8A

Consumption

≤ 5W ( without HDD, and PoE off )

Dimensions (mm)

255 × 222 × 42 ( W × D × H )

Working Environment

-10～50 °C, 10% ～ 90% humidity

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, REACH and WEEE
