Support 4/8 CH 6MP/5MP/4MP/3MP/1080P/ 960P/720P/960H/DI/CIF IP video input
H.265S/H.265+/H.265/H.264 coding
Intuitive and user-friendly Graphic User Interface ( GUI ), Windows style operation by mouse
Multi-type recording: manual / timed / motion / sensor / POS / AI recording
Playback : 4 /8CH simultaneous playback
Search : time slice, time, event, tag, smart search
Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, crowd density, etc.
Support POS information overlay on live view and playback
Express and flexible backup via USB, network and so on
Support preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
4/8 PoE network ports; IPCs can be directly connected to NVR; PoE power supply supported
Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Authorization management, log view and device status view
1080P HD output, true high resolution display
Support NAT function and QRCode scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Android OS
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Model | TD-3004H1-4P-B1 | TD-3008H1-8P-B1 | |
System | OS | Embedded Linux | |
Video | Network Input | 4 CH IPC input | 8CH IPC input |
Network Input Resolution | 6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF | ||
Output | HDMITM × 1 : 1920 × 1080 / 1280 × 1024/ 1024 × 768 VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768 | ||
HDMITM and VGA output the same video source | |||
Compression | H.265S / H.265+ /H.265 /H.264 | ||
Multi-screen Display | 1/4 | 1 / 4 / 6 / 8 / 9 | |
Audio | Network Input | 4 CH IPC audio input | 8 CH IPC audio input |
Local Input | No | ||
Local Output | No (HDMITM supports the audio output) | ||
Compression | G.711(U/A) | ||
Record | Resolution | 6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF | |
Frame Rate | 30fps/25fps(NTSC/PAL) | ||
Playback | Simultaneous Playback | Max. 4 CH | Max. 8 CH |
Search | Time slice / time / event / tag /smart search | ||
Smart Search | Highlighted color to display the camera record in a certain period of time, | ||
different colors refers to different record events | |||
Function | Play, pause, FF, FB, digital zoom, etc. | ||
Decoding Capability | Live View/ Playback | 1CH 6MP; | |
4CH 1080P | |||
Alarm | Type | Manual, sensor, motion, exception, smart events, etc. | |
Input | No | ||
Output | No | ||
Triggering | Record, snapshot, buzzer, preset, e-mail, etc. | ||
Network | Interface | RJ 45 100Mbps × 1 | |
Protocol | TCP / IP, HTTP, HTTPS, 802.1, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, | ||
IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP, ONVIF, etc. | |||
Incoming/ Outgoing Bandwidth | 40/64 (Mbps) | 64/64 (Mbps) | |
*When the AI function of the IPC is enabled, the actual incoming bandwidth(max.bitrate) is more than | |||
the set value in the NVR. | |||
Client Connection | Max. 64 users access | ||
Mobile Device | OS | iOS, Andriod | |
Storage | HDD Interface | SATA3.0 × 1, max 10T | |
Backup | Local Backup | USB flash drive | |
Network Backup | Yes | ||
Port | USB | USB 2.0 × 2 | |
Remote Controller | No | ||
PoE | PoE Ports | 100M RJ45 × 4 | 100M RJ45 × 8 |
Standards | IEEE802.3AF/AT | ||
Output Power | ≤ 40W | ≤72W | |
Others | Power Supply | DC 48V/1.25A | DC 48V/1.8A |
Consumption | ≤ 5W ( without HDD, and PoE off ) | ||
Dimensions (mm) | 255 × 222 × 42 ( W × D × H ) | ||
Working Environment | -10 ～ 50 ℃，10% ～ 90% humidity | ||
Certificate | CE, FCC | ||
Environmental Protection | Complies with Directive EU RoHS, REACH and WEEE | ||
