System

OS

Embedded Linux

Video

Compression

H.265S/H.265+/H.265/H.264

IP Video Input

32CH IPC input

Resolution

16MP/12MP/9MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/
960P/ 720P/960H/D1/CIF

Network Bandwidth

320Mbps/256Mbps(incoming/outgoing)
*When the AI function of the IPC is enabled, the actual incoming
bandwidth(max.bitrate) is more than the set value in the NVR.

Output

HDMI^TM1 : 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768
HDMI^TM2  :  1920  ×  1080  /  1280  ×  1024  /  1024  ×  768
VGA ×1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768
VGA and HDMI^TM1 output the same video source

Multi-screen Display

Main output: 1/4/6/8/9/13/16/25/32/36 (live view)
AUX output: 1/4/6/8/9 (live view)
Max. 32+9CH local live view

Audio

Network Input

32 CH IPC audio input

2-way Audio

RCA × 1

Local Output

RCA × 1

Compression

G.711(U/A)

Record

Record Stream

Dual stream recording

Resolution

16MP/12MP/9MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/
960P/720P/960H/D1/CIF

Frame Rate

NTSC: 30fps; PAL: 25fps

Playback

Simultaneous Playback

Max 16CH

Search

Time slice / time / event / tag / smart search

Smart Search

Highlighted color to display the camera record in a certain period of time,
different colors refers to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Decoding Capability

Live View/ Playback

Non-AI Mode:1×16MP@30fps/4×6MP@30fps/9×2MP@30fps/16×720P@30fps
AI Mode: 1×16MP@30fps/4×5MP@30fps/9×2MP@30fps/16×720P@30fps

Alarm

Mode

Manual, sensor, motion, exception, smart events, etc.

Input

16 CH local alarm input

Output

4 CH

Triggering

Record, snap, preset, e-mail, etc.

Face

Face Detection Performance
(AI by IPC)

32CH

Face Detection Performance
(AI by Device)

2 CH (2MP)

Face Match Performance

6 CH

Comparison Capability

18 pictures / second

Face Picture Database

32     libraries 10000 Face Pictures

Face Picture Search

Search by picture is supported

Database Management

Add, modify, delete and search face pictures

Face Picture Adding

Add face pictures through APP, WEB and external import

Face Picture Comparison

Support successful face recognition alarm and stranger match alarm

Track

Track display on a map

Statistical Graph of Information

Bar graph

Statistical Mode of Information

Statistics by day, week, month, quarter as well as customized time period

Perimeter Protection

Human/Vehicle Classification
(AI by IPC)

32CH

Human/Vehicle Classification
(AI by Device)

2CH (2MP)

Video Metadata

Human/Vehicle Attribute
Analysis(AI by IPC)

Yes

Other Functions

Fisheye

Supports fisheye dewarping via NVR/Web Client/mobile APP

Plate Recognition (AI by IPC)

Yes

Network

Interface

RJ 45 1000 Mbps × 2

Protocol

TCP / IP, HTTP, HTTPs, 802.1X, FTP, DHCP, DDNS, RTP, RTSP, RTCP,
NTP, UPnP, SMTP, IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP

Client Connection

Max. 128 users access

PoE

PoE Port

RJ 45 100Mbps × 16

Standard

IEEE802.3AF/AT

Output Power

≤ 150W

Mobile Device

OS

iOS, Andriod

Storage

HDD Interface

SATA ×8, max 10T for each HDD

E-SATA Interface

E-SATA × 1

Backup

Local Backup

U disk, USB mobile HDD

Network Backup

Yes

External Interface

RS 485

Yes (full-duplex), connect to PTZ or keyboard

USB

USB 3.0 × 1 ; USB 2.0 × 2

Remote Controller

Optional

Others

Power Supply

ATX 300W(PoE)

Consumption

≤ 30W ( without HDD and PoE power supply )

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, REACH and WEEE

Dimensions(mm)

445 × 436 × 90 ( W × D × H )

Working Environment

-10 〜 50 ℃，10% 〜 90% humidity
