Image sensor

1/2.7″ progressive scan CMOS with BSI and NIR+ technology

Max Resolution

2688x1520(4.08MP)

Mini. Illumination

Color:0.02 Lux @ (F1.6,AGC ON)；B/W：0.004 Lux @(F1.6，AGC ON); 0 Lux with IR

Image setting

Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client

Shutter Speed

50Hz: 1/25s~1/25,000s, 60Hz: 1/30s~1/30,000s

White Balance

Auto/Manual/Indoor/Outdoor

Gain

Auto/Manual

Day & Night

Auto/Manual

Aperture control

N/A

S/N Ratio

≥52dB

3D DNR

Auto/Manual

AE Enhancement

BLC, HLC, DWDR(suggest in still mode)

Digital Zoom

8X

Privacy Mask

4 Programmable privacy masks

Picture overlay

Logo picture could be overlaid on video with 128x128pixels,24bits JPG format

Font overlay

Max 15characters per line, 8lines max, white color or red color

OSD

Time, Date, Device Name, Zoom ratio, Direction(N/S/E/W),PTZ Status, etc.

Lens

Focus length

f=3.18mm~7.42mm(wide-tele) ±5%, about 3x optical zoom AF lens

Zoom Speed

1 second(Wide->tele)

Field of View

Horizontal: 113.6°(W)-44.3°(T); Vertical :59.6°(W)-24.9°(T) ; Diagonal:137.4°(W)-50.8°(T); ±5%

Mini View Distance

40cm

Aperture Range

F1.6 ~ F2.7 (wide-tele)±10%

IR Cut filter

Switchable ICR

DORI table

Lens

Detect(25px/m)

Observe(63px/m)

Recognize(125px/m)

Identify(250px/m)

f=3.18mm

62.8m(206 f.t)

24.9m(81.7 f.t)

12.56m(41.2f.t)

6.28m(20.6 f.t)

f=7.42mm

148.4m(487 f.t)

58.89m(193 f.t)

29.68m (97.4 f.t)

14.84m(48.7f.t)

PTZ

Pan Range

0~355°

Pan speed

Configurable, from 0.5~80°/s; Preset speed: 80°/s

Tilt Range

From 15°to 90°(auto flip at 90°) , (±1°)

Tilt Speed

Configurable, from 0.5°~ 80°/s, Preset speed: 80°/s

Pan/Tilt intervals

Default 300seconds, min 120seconds, max 3600 seconds. Customized per request

Proportional Zoom

Yes

Preset

360

Cruise

8 cruises, up to 16 presets for each cruises

Trace

N/A

Power off memory

Support

Action mode

Preset/Cruise(No trace or scan)

3D Positioning

Support

PTZ Position Display

Support

Schedule Task

Preset/Cruise/Dome reboot

Supplement Light

IR Distance

Up to 20m, 4pcs 850nm

Smart IR

Yes

Network

Main stream

25fps:(2688×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960, 1280×720);
30fps:(2688×1520, 2560×1440, 2048×1536, 1920×1080, 1280×960, 1280×720)

Sub stream

25fps (704 × 576, 640 × 480, 352 × 288)；30fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video compression

Smart H.265+/H.265/H.264+/H.264/MJPEG

H.264 Encoder

H.264/AVC codec BP/MP/HP, level 5.1

H.265 Encoder

H.265/HEVC codec MP, level 5.0

Video bit rate

H.264: 128kbps~16,384 kbps; H.265: 51 kbps~12,288kbps

Audio Compression

G.711 A/U

Audio bit rate

64Kbps

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP,
RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, P2P

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption,
IEEE802.1x port-based network access control; IP address filtering

API

ONVIF G/S/T, support TVT SDK and third-party management platform

Client

TVT N9000 1.4.7, TVT NVMS 2.0; and the third-party client, free iOS and Android App

Web Browser

IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free

Smart Features

Basic event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, SD error)

Face recognize

(Default off) human face detection, capture and face comparison.

Road traffic

Vehicle detecting and tracking, etc.

Smart Detection

Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, etc. More VCA per request.

Smart Tracking

Smart tracking of human or vehicle, auto/manual

System Integration

Audio Interface

1CH audio input, 2 to 2.4v[p-p] 1KΩ ±10%,bare Wire;
1CH audio output (line out), impedance: 600Ω,bare wire

Built-in mic

1-ch mic

Built-in Speaker

N/A

Audio device switch

Default use built-in MIC, manually switch to external

Alarm interface

1CH alarm input(DRY Connection); 1CH alarm output

Alarm Linkage

Alarm actions, such as Preset, Cruise, Memory Card Video Record, Trigger Recording, Notify Surveillance Center,
Upload to FTP/Memory Card, Send Email, etc.

Network Interface

1 RJ45 10M/100M Adaptive Ethernet (Support PoE)

Storage Slot

Card chamber, support microSD/TF card, up to 256GB

Serial interface

No RS485/RS232

Auxiliary video

N/A

Reset button

Yes

Heat and Fan

N/A

Water removal

Dust and Water-resistant coating for dome cover

General

Languages

Czech; English, German; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish; Russian,
Romanian, Spanish; Spanish(Mexico); Simplified Chinese; Turkish; Traditional Chinese. etc.

Power

DC12V±20% 2000mA or PoE(802.3.af). avg 7Watt;max 12Watt (IR + PTZ working)

Working condition

-30°C ~ 60°C (-22°F ~ 140°F) IR off, -30°C ~ 40°C IR on; Cold start≥- 20°C(1Hour waiting), ≤90%RH

Storage condition

-40°C ~ 60°C ; ≤ 95% RH

Protection

6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Shield Material

Main body: Aluminum Alloy(ADC12); Bubble: Polycarbonate

Dim& Net weights

￠116mm x 75mmH  (￠4.56′x 2.95′)，Approx. 463g( 1 lb.)

Certification

IP67,IK10(include lens bubble), ROHS,CE,FC,UKCA,KC,BIS
