Camera

Image Sensor

1 / 1.8" CMOS

Image Size

2560 × 1440

Electronic Shutter

Auto/manual; Manual mode: 1 /3s ~ 1 / 100000 s

Iris Type

DC Iris

Min. Illumination

Color: 0.0009 lux@F1.2,AGC ON B&W:0.0004 lux@F1.2,AGC ON

Lens Mount

CS

Day & Night

ICR

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

S/N Ratio

≥50dB

Digital NR

3D DNR


Video Compression

Main stream: H.265+ /  H.265  /  H.264+  /  H.264

Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),1080P ( 1920 × 1080 ),

720P ( 1280 × 720 ), D1, VGA(640 × 480), 480 × 240, CIF

Main Stream

4MP/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Sub Stream

720P/D1/CIF/VGA/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, Image Mirror, Image Flip, NR, etc.

adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45 10M/100M self-adaptive Ethernet port

Video Output

CVBS output (BNC × 1)

Audio

1CH audio input; 1CH audio output; 1CH built-in MIC

Alarm

2CH alarm input; 2CH alarm output

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

RS 485

Yes
