Camera

Image Sensor

1 / 2.8" CMOS

Image Size

1920 × 1080

Electronic Shutter

1 / 25 s ~ 1 / 100000 s

Iris Type

DC-IRIS

Min. Illumination

0.0026 lux@F1.2, AGC ON; 0 lux with LED

0.005 lux@F1.6, AGC ON; 0 lux with LED

Lens

7~22mm@F1.6, motorized;

Recommended face capturing distance: 4~10m

Field of View

Horizontal: 44°~17.6°; Vertical:25.6°~10°; Diagonal: 49.7°~20.2°

Lens Mount

Φ14

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~360°; Tilt:0°~80°; Rotation: 0°~360°


Video Compression

Main stream: Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264

Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240

Main Stream

60Hz : 1080P/ 720P (1 ~ 30fps ); 50Hz : 1080P/ 720P (1 ~ 25fps )

HFR mode: 1080P/720P (60Hz: 1~60fps; 50Hz: 1~50fps)

Sub Stream

60Hz : 720P/D1/CIF (1~30fps); 50HZ:720P/D1/CIF (1~25fps)

Third Stream

60Hz : D1/CIF 480 ×240 (1~30fps); 50Hz: D1/CIF 480 ×240 (1~25fps)

Bit Rate

64 Kbps ~ 6 Mbps

Bit Rate Type

VBR / CBR

Image Settings

ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen, NR, etc. adjustable through client software or web browser

Audio Compression

G711A/U

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45

Video Output

No

Audio

1CH audio input; 1CH built-in MIC

Storage

Built-in micro SD card slot, up to 256GB

Reset

Yes

Functions

Remote Monitoring

Web browsing,CMS remote control

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, ICMP, IGMP, FTP, PPPoE, DDNS, SMTP,SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection; SD card full SD card error

Intelligent Analytics

Face detection, face capture, face match, video blur detection, video color cast detection, scene change detection

General Function

Watermark, IP address filtering, video mask, heartbeat, password protection, non-photosensitive switch, face exposure

PoE

Yes (802.3af)

LED View Distance

10 m soft light

Ingress Protection

IP 67

Face Detection

Face Detection

Pupil distance of a facial image over 20 pixel can be detected

Face Capturing

By precise detecting, tracing, capturing, scoring and screening the moving faces to get the most effective face snapshots

Panorama Capturing

Support panorama capturing and self-defined information overlay, like device ID, time, etc.

Intelligent Light Compensation

Built-in high efficient white light LEDs, time switch available

Face Picture Database

10000 face pictures

Database Management

Add, modify, delete and search face pictures

Face Picture Adding

Add face pictures through WEB and Face Album Manager Tool

External Face Picture Enrollment

Size: less than 70KB Format: jpg, jpeg

Face Picture Comparison Alarm

Support face trigger modes

Support allow list, block list, stranger alarms

Others

Power Supply

DC12V/PoE

Power Consumption

< 11W

Operating Environment

- 30 °C ~ 60 °C (-22°F~140°F)

Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

Ø111.6 × 99.6

Weight ( net )

Approx. 0.64KG

Installation

Wall mounting; ceiling mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
