Camera

Image Sensor

1 / 2.9 "CMOS

Image Size

2688 × 1520

Electronic Shutter

Auto or manual mode; manual mode: 1 / 3s ~ 1 / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.0005 lux @F1.0, AGC ON; 0 lux with illumination on

S/N Ratio

≥50dB

Lens

2.8 mm@F1.0, H.FoV: 99°; V.FoV:53°; D.FoV: 119°
3.6 mm@F1.0, H.FoV: 81°; V.FoV: 44°; D.FoV: 96°

Focus

Fixed

Lens Mount

M12

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

EIS

Yes

Angle Adjustment

Pan: 0°~360°; Tilt:0°~75°; Rotation: 0°~360°


Video Compression

Main stream:H.265+/H.265/H.264+/H.264
Sub stream/Third stream: H.265+/ H.265 / H.264+ / H.264/ MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP (2688×1520),2K (2560×1440), 1080P (1920×1080), 720P (1280×720 ), D1, VGA (640 ×480), 640 ×360, CIF, 480×240

Main Stream

4MP/2K/1080P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Sub Stream

720P/D1/640 ×360/VGA/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

720P/D1/640 ×360/VGA/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

32 Kbps ~8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast,Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc.
adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45 (10/100 Base-T)

Video Output

No

Audio

1CH audio input; 1CH built-in microphone

Storage

Built-in micro SD card slot; up to 512GB

Reset

Yes

Alarm

No

Intelligent Analytics

Smart Event

Line crossing, region intrusion/entrance/exiting (human/vehicle classification), abandoned/ missing object detection

Statistics

Target counting by line (human/vehicle classification)

Exception Detection

Scene change, video blur and abnormal color detection, audio exception

Face Detection

Face detection, face capture

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

61m(200ft)

24m(80ft)

12m(40ft)

6m(20ft)

3.6mm

75m(247ft)

30m(99ft)

15m(49ft)

8m(25ft)

Functions

Remote Monitoring

Web Client/TVT NVR/NVMS/mobile APP

Web Browser

Chrome 92.0+/Edge 92.0+/Firefox 91.0+/Safari 13.1+

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, P2P, QoS

Interface Protocol

ONVIF

API & SDK

Yes

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, SMD, SD card error, SD card full, IP address conflict, Network disconnection

General Function

Watermark, video mask, heartbeat, image distortion correction, corridor pattern, ANR, cloud upgrade, disarming

Security

Video encryption, firmware encryption, HTTPS encryption, configuration encryption, illegal login lock, IP address filtering, 802.1x authentication,
basic and token authentication for HTTP/RTSP

PoE

Yes , IEEE802.3af

White Light Range

10 ~20 m

Ingress Protection

IP 67

Others

Power Supply

DC12V/PoE

Power Consumption

< 7W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

Ø 94.6 × 82.8

Weight ( net )

Approx. 0.456KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
