High-performance X86 hardware platform, stable and reliable
Preset software before delivery; All-in-One simple deployment
Supports the device access of TVT and other famous manufacturers in the industry,Supports ONVIF protocol
Supports standard, widescreen and customized screen display modes
Supports instant playback and alarm preview
Supports PTZ direction control and focus control; supports setting and calling preset and cruise
Supports voice monitoring, two-way talk and broadcast
Supports multi-level images and online E-map
Supports TV wall management, including splicing, PIP, roaming and triggering video on TV wall
Supports Android/iOS mobile APP
Integrated Intel Xeon E3-1220V5 high-performance 4 core processor, up to 8GT/s data transfer rate, 64 bit expansion, I/O acceleration, Turbo, Hyper-Threading Technology
4 memory card slots, up to 64GB DDR4-1866/2133MHz ECC
2 gigabit Ethernet ports; support I/OA technology; support link aggregation and binding redundancy; support iKVM;IPMI×1
12Gbps SAS Expander, 12Gbps RAID card (RAID 0, 1, 5, 6 supported)
16 *3.5 inch hot-pluggable HDD slots, up to 256TB
3 control expansion slots: 1*PCI-E3.0x16(x8); 1*PCI-E3.0x8; 1*PCE-E3.0x8(x4)
550W 1+1 redundant power supply
Monitoring various status of the storage server, such as connection status, network status, hardware status and so on; judging the fault level according to the buzzer sound; timely recording event information and operation logs of the device; providing full solution of real-time monitor and alarm of the device
Provide TPM interface which supports TPM standard security chip, so that the device can be protected effectively in case of the illegal user access
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Free Shipping apply to all orders over $100
Guaranteed 100% Organic from natural farms
1 Day Returns if you change your mind
Covid-19 Info: We keep delivering.
Model | TD-A616E-E |
CPU | Intel Core Processor I3 |
OS | Linux |
Memory | 8GB DDR4 ECC,up to 64GB DDR4ECC memory |
HDD | 3.5 inch SATA x 16 (hot-pluggable); built-in 2.5 inch SATA x 2 |
HDD Installation | Independent HDD bracket |
Capacity | Up to 256TB (max.16T per HDD) |
RAID | Hardware RAID; support RAID 0, 1, 5, 6 |
Expansion | 1*PCI-E3.0x16(x8);1*PCI-E3.0x8;1*PCE-E3.0x8(x4) |
Network Card | Integrated I210-AT dual gigabit network cards, load balancing and if one is offline, the other will replace |
IPMI | ASPEED AST2400 BMC, independent IPMI interface; support iKVM |
Protocol | Support TCP / UDP / RTSP protocol |
Search | Built-in index, accurate to second-level |
Performance | Up to 700Mbps incoming, 700Mbps recording and 96Mbps playback Up to 700Mbps incoming, 700Mbps recording and 96Mbps live view |
Way of Management | WEB management, seamless access to NVMS |
Capability of Management | RAID management, record management, system log as well as alarm processing |
Max. Number of Channel Access | 2048 CH(extensible to 10000CH via the transfer server) |
Max. Number of Device Access | 500 devices (extensible to 10000CH after it is authorized) |
Max. Number of Channel Access of Single Transfer Service | 2048CH |
Max. Number of Device Access of Single Transfer Service | 300 DVRs/NVRs or 500IPCs |
Max. Decoding Output Number | 128CH |
Max. Number of Transfer Server Access | 32 |
Max. Number of Storage Server Access | 32 |
Max. Number of Channel Access of Third-party protocol | 16(extensible to 10000CH after it is authorized) |
Max. Number of Device Access of Third-party protocol | 4(extensible to 10000CH after it is authorized) |
Max. Channel Number of Simultaneous Preview | 100 (for one client/user) |
Max. Channel Number of Simultaneous Playback | 16 (for one client/user) |
Max. Number of Views | Up to 64 view plans can be created |
Max. User Access | Max. 64 users (extensible to 1024 users access after it is authorized) |
Max. Online Users | 64 users preview simultaneously |
Security | Supply TPM interface; TPM module installation supported |
Interface | 1× VGA, 6× USB(4 in the real panel and 2 in the front panel), 2× RJ 45, 1× IPMI, 1× RS 232 |
Power Supply | 550W 1+1 redundant power supply, 100~240V-7~3.4A /50~60Hz |
Temperature | Working: 10°C to 35°C; standby: –40°C~+55°C(ambient) |
Relative Humidity | Working: < 90% RH(35°C) |
Noise | Working: < 50Dba |
ESD | Each item conforms to Intel ambient temperature test standard 15KV |
