Camera

Image Sensor

1/2.8" Progressive Scan CMOS

Image Size

1920×1080

Electronic Shutter

1/2s ~ 1/100000s

IRIS Type

Fixed IRIS

MIN. Illumination

0 lux

Lens

2MP dual lens; f=3.97mm @F1.6

Vertical horizontal field of view: approx. 87°，horizontal field of view: approx. 44°

Lens Mount

M12

WDR

120dB

BLC

Yes

HLC

Yes

Defog

Yes

DNR

2D/3D NR


Video Compression

H.265+/H.265/ H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Bit rate Type

VBR/CBR

Bit Rate

64Kbps ~ 6Mbps

Resolution

1080P(1920×1080), 720P(1280×720), D1, CIF, 480 ×240

Main Stream

60Hz: 1920×1080/1280×720(1~30fps); 50Hz:1920×1080/1280×720(1~25fps)

Sub Stream

60Hz: 720P/D1/CIF(1~30fps); 50Hz: 720P/D1/CIF(1~25fps)

Third Stream

60Hz: D1 /CIF /480 ×240 (1~30fps); 50Hz: D1/CIF /480 ×240 (1~25fps)

Image Setting

Saturation, hue, brightness, contrast, wide dynamic range, sharpness, NR, etc., adjustable through client or web browser

Audio Compression

G711A/U

Screen

8 inch Screen

Resolution: 800 (RGB) × 1280

Brightness

300cd/m2

Card

Card Type

Mifare card /Desfire card/FM1208 Card/Gicard

Card Reading Protocol

ISO14443A/B

Card Reading Frequency

13.56MHz

Card Reading Duration

<1s

Card Reading Distance

0~2cm

Interfaces

Network

100M RJ45

Audio

Built-in MIC×1, built-in speaker×1

Door Lock Output

1CH

Exit Button

1 CH

Door Contact Input

1 CH

Anti-Tamper Interface

1 CH

Reset Button

1

Alarm

2CH alarm input; 2CH alarm output

USB

Yes

Storage

1CH built-in micro SD card slot, up to 256G

RS485

Yes

Wiegand Interface

Yes (Wiegand input or output configurable)

Function

Remote Monitoring

IE browser/CMS remote control

Online Connection

Supports simultaneous monitoring for up to 10 users

Supports multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, UPnP, HTTPS, HTTP

Interface Protocol

ONVIF

Storage

Network remote storage

Smart Alarm

IP address conflict, cable disconnection

Intelligent Analytics

Liveness Detection, face detection, mask detection, face capture, face match, scene change detection, video blur

detection, video cast detection

General Function

Watermark, IP address filtering, video mask, heartbeat, illegal login, image distortion correction

White Light Distance

0.3-1.5m soft light

IR Light Distance

0.3-2m

Ingress Protection

IP66

Face

Height Range of Face Recognition

1.2m-2.2m (the recommended installation height is 1.45m, based on the tester’s height of 170cm)

Face Recognition Distance

0.3m-1.5m (the recommended face recognition distance is from 0.5m to 1m)

Face Detection

Pupil distance of a facial image over 20 pixel can be detected

Face Capture

Outputting the optimal face image by precise detecting, tracing, capturing, scoring and screening the moving faces

Original Image Capturing

Supports original image capturing and self-defined overlaid information (like device ID, time, etc.)

Face Picture Database

50,000

Face Comparison Storage

30,000

Database Management

Face pictures can be added, modified or deleted in the face database.

Face Picture Adding

Adding face pictures through face recognition terminal, WEB, face album manager tool, USB storage device import

Face Comparison Alarm

Face detection alarm, allow list, block list and stranger alarm

Intelligent Light Compensation

Built-in high efficient white light LEDs

Others

Power

DC12V/1A

Power Consumption

< 12W

Environmental Protection

RoHS 2.0, REACH, WEEE, directive94/62/EC

Working Environment

-20℃~50℃, Humidity: less than 95% (non-condensing)

Dimensions(mm)

285.8×138.6×30.5

Weight (net)

Approx. 1.174 kg

Installation

Wall mounting; Standing on desktop; Pole mounting, etc.
