Image sensor

1/2.8” progressive scan CMOS image sensor x8

Mini. Illumination

Color：0.008Lux @ (F2.0,AGC ON)；B/W：0.008Lux @(F2.0，AGC ON);0Lux with IR

Image setting

Image vertical rotation, Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client software/browser

Shutter Speed

1/1 s – 1/100,000 s

White Balance

Auto/Manual/Indoor/Outdoor

Gain

Auto/Manual

Day & Night

IR Cut filter

Privacy Mask

8 Programmable privacy masks

Image Enhancement

3D DNR, Digital zoom, Logo picture Overlay

Vertical Rotation

Manual adjustment, 8 pitches,  45°per pitch

Lens

Focus length

3.3mm,x8

Aperture

F2.0

FOV

Panoramic image: Horizontal FOV: 2x180°(360°)；Vertical  FOV: 85°

Working distance

1.0m ~ INF

IR

IR Range

20m in radius,360°(H) × 90°(V)

Smart IR

Yes

Network

Max Resolution

8192 ×1800, 25/30fps

Main stream

8192 ×1800 , 3840 × 1680 , 2784 × 1200 (1~30fps)

Sub stream:

2048 × 896, 1280 × 560 , 704 × 320 (1~30fps)

Third stream:

704 × 320 ( 1~30fps )

Video compression

H.265/H.264/ MJPEG

Audio compression

G.711 A/U

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE

Simultaneous live view

Up to 6 channels

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address);

HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering

Smart Features

Basic event

Motion detection, video tampering alarm,

exception (network disconnected, IP address conflict, SD full, SD error)

Smart Detection

Up to 8 regions configurable: Human/vehicle detection and classification, Face comparison, Intrusion detection,

 Line crossing detection,Region entrance detection, Region exiting detection, Scene change detection, etc.

ROI

Up to 4 regions configurable

Alarm Linkage

Upload to FTP/Memory card, send email, trigger alarm output, trigger recording, trigger snapshot

System Integration

Alarm Interface

1CH alarm input; 1CH alarm output

Audio Interface

1CH audio input, 2 to 2.4v[p-p] 1kΩ±10%; 1CH audio output (line out), impedance: 600Ω

Network Interface

1 RJ45 10M/100M/1000M Adaptive Ethernet (Support PoE++(802.3.bt,class 6))

Storage

Built-in memory card slot, support microSD/SDHC/SDXC, up to 256G

API

ONVIF, support TVT SDK and third-party management platform

Client

TVT NVR N9000 1.4.6, TVT NVMS 2.0(Support VR, e-Tag, e-map application)

Web Browser

IE8-11

General

Power

AC24V,DC24V,PoE++ (802.3.bt, class 6), (Max 45W, include IR on, Fan on and Heater on)

Working condition

-30°C ~ 55°C (-22 °F ~ 131 °F),90%RH less (non-condensing),Cold start at - 20°C

Storage condition

-40°C ~ 70°C ;≤ 95% RH

Protection

IP 66, IK10, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Material

Camera body: Aluminum Alloy; Bubble and IR cover: Plastic

Dimensions

￠273mm x H 180mm( ￠10.7” x 7”)

Weight

Net weight Approx. 2.0Kg(4.4 lb)

Certification

IK10(exclude plastic cover), IP66,ROHS, CE, FC
