Image Sensor

1/2.7″ progressive scan CMOS with BSI and NIR+ technology

Max Resolution

2560×1440

Mini. Illumination

Color：0.01 Lux @ (F1.6，AGC ON)；B/W：0.002Lux @(F1.6，AGC ON);0Lux with IR

Image Setting

Saturation, Brightness, Contrast, Sharpness, AGC, and AWB adjusted by client

Shutter Speed

50Hz:  1/25s~1/25,000s,  60Hz: 1/30s~1/30,000s

White Balance

Auto/Manual/Indoor/Outdoor

Gain

Auto/Manual

Day & Night

Auto/Manual

Aperture Control

N/A

S/N Ratio

≥52dB

3D DNR

Auto/Manual

AE Enhancement

BLC, HLC, WDR

Privacy Mask

4 Programmable privacy masks

Picture Overlay

Logo picture could be overlaid on video with 128x128pixels,24bits JPG format

Font Overlay

Max 15characters per line, 8lines max, white color or red color

Lens

Focus Length

f=2.8-12mm lens,4x optical

Zoom Speed

About 1.6second(Wide->tele)

Field of View

Horizontal: 97° to 31°±5%;Vertical: 51° to 18°±5%; Diagonal: 115° to 36°±5% (wide-tele)

Working Distance

1m to infinite (object to lens distance)

Aperture Range

F1.6~ F2.7 (wide-tele)

IRCut Filter

Electrical switchable ICR

DORI table

Lens

Detect(25px/m)

Observe(63px/m)

Recognize(125px/m)

Identify(250px/m)

2.8mm

68m(223 f.t)

27.1m(88.9 f.t)

13.6m(44.6 f.t)

6.8m(22.3 f.t)

12mm

206.7m(678.1 f.t)

82m(269 f.t)

41.3m (135.5 f.t)

20.7m(68f.t)

PTZ

Pan Range

0~355°

Pan speed

Configurable, from 0.5~80°/s; Preset speed: 80°/s

Tilt Range

From -5° to 90°

Tilt Speed

Configurable, from 0.5°~ 60°/s, Preset speed: 60°/s

Pan/Tilt Action Interval

At least 10seconds, adjustable

Proportional Zoom

Yes

Preset

360

Cruise

8 cruises, up to 16 presets for each cruises

Trace

4 traces, record time over 3 minutes for each trace

Power off Memory

Support

Action Mode

Preset/Cruise/Trace/Auto Scan/Random Scan

3D Positioning

Support

PTZ Position Display

Support

Schedule Task

Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot

Supplement Light

IR Distance

4pcs of IR Array into 2 Groups, auto switch with zoom ratio

Smart IR

Yes

White light Distance

2pcs of White LED Array

White light Mode

Flush mode, torque mode

Network

Main Stream

25fps (2560×1440, 2048×1536, 1920×1080, 1280×960, 1280×720);30fps (2560×1440, 2048×1536, 1920× 1080, 1280× 960, 1280× 720)

Sub Stream

25fps (704 × 576, 640 × 480, 352 × 288)；30fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288)；30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video Compression

Smart H.265+/H.265/H.264+/H.264/MJPEG

H.264 Encoder

H.264/AVC codec BP/MP/HP, level 5.1

H.265 Encoder

H.265/HEVC codec MP, level 5.0

Video Bit rate

64Kbps ~ 16Mbps

Audio Compression

G.711 A/U

Audio Bit rate

64Kbps

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,DHCP, PPPoE

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption,
IEEE802.1x port-based network access control; IP address filtering

Smart Features

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, SD error)

Face Recognition

(Default N/A)human face detection capture, face comparing( per request)

Road Traffic

Vehicle detecting and tracking, etc.

Smart Detection

Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, etc.

Smart Tracking

Smart tracking of human or vehicle, auto/manual

Active Deterrence

Flush strong white light and predefined voice upon invaders detected.

Dual Way Talk

One way talk.

System Integration

Ext. Audio Interface

1-ch audio input(mic in),2.0-2.4Vp-p,1kΩ±10%;1-ch audio output(line out),line level,impendance:600 Ω;

Built-in Speaker

Yes, One Speaker, 4Ω, 2.5Watt. Rotation with camera, up to 30m distance audible

Built-in MIC

1channel, rotation with camera lens direction, up to 8m distance voice recordable.

Audio Device Switch

Default use built-in speaker and MIC, manually switch to external

Alarm Interface

1CH alarm input(Dry contact); 1CH alarm output

Alarm Linkage

Alarm actions, such as Preset, Cruise, Trace, Memory Card Video Record, Trigger Recording,
Notify Surveillance Center, Upload to FTP/Memory Card, Send Email, etc.

Network Interface

1 RJ45 10M/100M Adaptive Ethernet (Support PoE+ )

Storage Slot

Standalone memory card chamber, support microSD/TF card, up to 256GB

Serial Interface

N/A

Auxiliary Video Out

N/A

Reset button

Yes

Heat and Fan

N/A

Water Removal

Dust and Water-resistant coating

API

ONVIF, support TVT SDK and third-party management platform

Client

TVT N9000 1.4.5, TVT NVMS 2.0; and the third-party client, free iOS and Android App

Web Browser

IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free

General

Languages

Czech; English, German; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish; Russian, Romanian,
Spanish; Spanish(Mexico);Simplified Chinese; Turkish; Traditional Chinese. etc.

Power

DC12V±20%,2000mA,orPoE+ (802.3.at,class 3),
AVG 3.3W,MAX14.9W at day;18.9W at night(LED on+ Speaker on + PTZ working)

Working Condition

-40°C ~ 55°C (-40°F ~ 131°F) IR off, -40°C ~ 40°C IR on; Cold start≥- 25°C(1Hour waiting), ≤90%RH

Storage Condition

-40°C ~ 70°C ; ≤ 95% RH

Protection

6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Shield Material

Main body: Aluminum Alloy(ADC12),Decoration: Polymer(Glass fiber and Plastic)

Dimensions

￠130mm x 162mmH  (￠5.1′x 6.4′)

Net Weight

Approx. 1.2Kg (2.645lb.)

Certification

IP66,IK10,ROHS,CE,FC,UKCA
