Image sensor

1/2.8" progressive scan CMOS image sensor, with BSI and NIR++

Max resolution

1920x1080

Mini. Illumination

Color ： 0.002Lux @ (F1.6 ， AGC ON) ； B/W ： 0.0004Lux @(F1.6 ， AGC ON);0Lux with IR

Image setting

Flip, Mirror, Saturation, Brightness, Contrast, Sharpness, AGC, etc. adjusted by client

Shutter Speed

60Hz: 1/30s – 1/30,000s; 50Hz: 1/25s~1/25,000s

White Balance

Auto/Manual/Indoor/Outdoor

Gain control

Auto/Manual

Day & Night control

Auto/Manual ,time schedule.( threshold:0.1lux)

Iris control

Auto/Manual, 16 steps adjustable.

SNR

≥52dB

3D DNR

Auto/Manual

AE Enhancement

BLC, HLC, 120dB WDR/HDR

Electronical Stabilizer

N/A(No gyro-scope)

Privacy Mask

4 areas, up to 8 mask per request.

Picture overlay

Logo picture could be overlaid on video with 128x128pixels,24bits format

OSD overlay

Max 15 characters/line, 8 lines, white or red font color

Lens

Focus length

f=5-75mm lens,15x optical zoom

Zoom Speed

Approx. 2.4s (optical zoom, wide-tele)

Field of View

Horizontal: 54° ~ 4° ;Vertical: 32° ~ 2.3°;Diagonal: 64.5° ~4.6°.(Wide-Tele), ± 5%

Image distance

Wide: 1.0m ~ INF; tele: 1.5m ~ INF

Aperture Range

Max F1.6

Iris Type

DC_IRIS

IRCut type

Removable IRCut filter

DORI distance

Focus length

Detect

Observe

Recognize

Identify

f=5mm

73m(239.5 f.t.)

29m(95.1 f.t.)

14.6m(47.9 f.t.)

7.3m(23.95 f.t.)

f=75mm

883m(2897 f.t.)

350.4m(1149 f.t.)

176.6m(579.4 f.t.)

88.3m(289.7 f.t.)

PTZ

Pan Range

360°endless

Pan speed

Configurable, from 0.1~80°/s; Preset speed: 80°/s

Tilt Range

From -10° to 90°,auto flip

Tilt Speed

Configurable, from 0.1°~ 80°/s, Preset speed: 80°/s

Proportional Zoom

Yes

Preset

360

Cruise

8 cruises, up to 16 presets for each cruises

Trace

4 traces, record time over 3 minutes for each trace

Power off memory

Support

Action mode

Preset/Cruise/Trace/Auto Scan/Random Scan

3D Positioning

Support

PTZ Position Display

Support

Schedule Task

Preset/Cruise/Trace/Random Scan/Boundary Scanning /Dome reboot

IR

IR Distance

200m (492 f.t.) ,850nm, 6 IR

Smart IR

Yes

Network

Main stream

50Hz: 1920 ×1080,1280 ×960,1280 ×720 @25fps; 60Hz: 1920 ×1080,1280 ×960,1280 ×720 @30fps

Sub stream

50Hz: 704 × 576, 640 × 480, 352 × 288 @25fps; 60Hz: 704 × 480, 640 × 480, 352 × 240 @30fps

Third  Stream

50Hz: 1920 × 1080,1280 × 960,1280 × 720, 704 × 576, 640 × 480, 352 × 288 @25fps

60Hz: 1920 × 1080,1280 × 960,1280 × 720, 704 × 480, 640 × 480, 352 × 240 @30fps

Video compression

H.265/H.264+/H.264/MJPEG

H.264 Standard

H.264/AVC codec BP/MP/HP, Level 5.1

H.265 Standard

H.265/HEVC codec MP, level 5.0

Video Bit Rate

64Kbps to 16Mbps

Audio compression

N/A(G.711 A/U)

Audio Bit Rate

N/A(64K bps)

Protocols

HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, DHCP, PPPoE,P2P

User / Host

Up to 16 users, 3 levels: Administrator, Advanced User and Normal User

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption,

IEEE802.1x port-based network access control; IP address filtering

API

ONVIF G/S/T, support TVT SDK and third-party management platform

Client

TVT N9000 1.4.5, TVT NVMS 2.0; and the third-party client, free iOS and Android App

Web Browser

IE8-11 with plug-in; Edge, Chrome, Firefox with plugin free

Smart Features

Basic event

Motion detection, Video tampering alarm, Exception(Network disconnected, IP address conflict, SD full, SD error)

Face recognize

Default ban (Open per local policy and request)

Road traffic

Vehicle detecting and tracking

Smart Detection

Tripwire, Bi-directional tripwire, Illegal intrusion detection, Region entrance detection, Region exiting detection, etc. More VCA per request.

Smart Tracking

Smart tracking of human or vehicle, auto/manual

System Integration

Alarm Interface

N/A

Audio Interface

N/A

Alarm Linkage

Alarm actions, such as Preset, Cruise, Track, Memory Card Video Record, Trigger Recording, Upload to FTP/Memory Card, Send Email, etc.

Network Interface

1 RJ45 10M/100M Adaptive Ethernet ,Support PoE( 802.3.af,class 3)

SD Card Slot

One MicroSD slot, up to 256G

RS 485

N/A

BNC

N/A

Built-in Speaker &Mic

N/A

Reset button

Yes

Built-in Heater &Fan

N/A

Water removal

Support (built-in raindrops eyebrow, lotus coating glass, quick-spinning)

Frost removal

Desiccant, Vacuumize

Ice removal

N/A

General

Languages

Czech; English, German ; Hungarian ; Italian ; Japanese ; Korean ; Portuguese, Polish; Russian, Romanian,

Spanish; Spanish(Mexico);Simplified Chinese; Turkish; Traditional Chinese, etc.

Power Supply

DC12V±25%,2000mA ,PoE (802.3.af, class 3), max 12W include IR ON+PTZ working

Working condition

-30°C ~ 65°C (-22°F ~ 149°F), IR OFF; -30°C ~ 45°C(-40°F ~113°F ), IR ON;

Cold start at - 20°C (0.5-1 hour waiting); 90%RH

Storage condition

-40°C ~ 70°C ; ≤ 95% RH

Protection

IP66, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection

Shield Material

Front cover: Aluminum Alloy; Main body: PC+GF15%;Decorating parts: PC+ABS/GF

Dimensions

Φ 173mm × 268mm (Φ6.8 inch × 10.55 inch)

Net Weight

Approx. 2.0 Kg (4.4 lb.)

Certification

IP66,IK10(excluding glass window),ROHS,CE,FC
