Camera

Image Sensor

1 / 2.8 "CMOS

Image Size

3840×2160

Electronic Shutter

Auto/Manual mode; manual: 1 / 3 s ~ 1 / 100000 s

Iris Type

DC Iris

Min. Illumination

Color: 0.01 lux @ F1.2, AGC ON; B&W: 0.0053 lux@ F1.2, AGC ON

Lens Mount

CS

Wide Dynamic Range

120dB

Day&Night

ICR

BLC

Yes

HLC

Yes

Defog

Yes

S/N Ratio

≥50dB

EIS

Yes

Digital NR

3D DNR


Video Compression

Main stream: H.265+ /  H.265  /  H.264+  /  H.264
Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG
Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

8MP ( 3840 × 2160 ), 6MP( 3072 × 2048 ),5MP( 2592 × 1944), 4MP( 2592 ×1520 ), 2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),
1080P ( 1920 × 1080 ), 720P ( 1280× 720 ), D1, CIF, 480 × 240, VGA(640×480)

Main Stream

8MP/6MP/5MP/4MP/2K/3MP/1080P/720P(60Hz : 1~30fps; 50Hz : 1~25fps)
HFR Mode: 1080P/720P(60Hz: 1~60fps; 50Hz: 1~50fps)

Sub Stream

720P/D1/CIF/VGA/480 ×240(60Hz:1 ~ 30fps; 50Hz: 1 ~ 25fps )

Third Stream

720P/D1/CIF/480 ×240(60Hz:1 ~ 30fps; 50Hz: 1 ~ 25fps )

Bit Rate

64 Kbps ~ 12 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, image flip, image mirror, Sharpness, NR,etc.
adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ 45 10M/100M self-adaptive Ethernet port

Video Output

CVBS output (BNC × 1)

Audio

1CH audio input; 1CH audio output, 1CH built-in MIC

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

Alarm

2CH alarm input; 2CH alarm output

RS 485

Yes

Intelligent Analytics

Smart Event

Line crossing, region intrusion/entrance/exiting, loitering detection, illegal parking detection, abandoned/ missing object detection

Statistics

Target counting by line/area, heat map

Exception Detection

Scene change, video blur and abnormal color detection, audio exception

Face Detection

Face detection and face capture

Video Metadata

Simultaneously captures human body, motor vehicle and non-motor vehicle and extracts 13 human features, 5 motor vehicle features and 1 non-motor vehicle feature

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTMP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, HTTP POST, 802.1x, UPnP, HTTPs, QoS

Interface Protocol

ONVIF(profile S, G, T, M)

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, sensor detection, SD card error, SD card full, IP address conflict, cable disconnection

General Function

Watermark, video mask, heartbeat, image distortion correction, corridor pattern

Security

Video encryption, firmware encryption, HTTPS encryption, configuration encryption, illegal login lock, IP address filtering,
802.1x authentication, basic and digest authentication for HTTP/RTSP

PoE

Yes , IEEE802.3af

IR Distance

No

Weather-proof Grade

No

Others

Power Supply

AC24V/DC12V/PoE

Power Consumption

< 11W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

160.8 × 79 × 64

Weight ( net )

Approx. 0.5KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
