Camera

Image Sensor

1 / 1.79 "CMOS

Image Size

2592 × 1520

Electronic Shutter

1/3 s ~ 1 / 10000 s

Iris Type

P Iris

Min. Illumination

0.007 lux@F1.4,AGC ON; 0 lux with IR

Lens

2.8~12mm@F1.36~F2.0, motorized

8~32mm@F1.7, motorized

Field of View

H:114.2°~47.94°; V: 59.36°~27.07°; D: 141.1°~55.09°

H: 40.6°~14°; V: 22.6°~9°; D: 47.3°~16°

Lens Mount

Integrated

Day & Night

ICR

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360°


Video Compression

Main stream: Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264

Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP ( 2592 × 1520 ), 2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240

Main Stream

4MP/2K/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

HFR mode: 1080P / 720P( 60Hz : 1 ~ 60fps; 50Hz: 1~50fps )

Sub Stream

720P/D1/CIF/480 × 240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

D1/CIF/480 × 240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR, Image Flip, Image Mirror, etc. adjustable through client software or web browser

ROI

8 ROI; Each ROI to be configured separately

Interfaces

Network

RJ 45

Video Output

CVBS output (BNC × 1, 1Vpp, 75 Ω)

Audio

1CH audio input; 1CH audio output

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

Alarm

1CH alarm input; 1CH alarm output

RS 485

Yes

DC12V Output

Yes(Max. output current: 200mA)

Intelligent Analytics (Smart Events)

Perimeter Protection

Line crossing, region entrance/exiting/intrusion (human/motor vehicle/ non-motor vehicle classification)

Statistics

Target counting by line/ area, heat map

Exception Detection

Scene change, video blur and video cast detection

Face Recognition

Face detection, face capture, face match

License Plate Detection

Yes

Other Events

Crowd density detection, abandoned/missingobject detection

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8~12mm(W)

53.34m(175ft)

21.34m(70.01ft)

10.67m(35ft)

5.33m(17.48ft)

2.8~12mm(T)

126.29m(414.33ft)

50.51m(165.71ft)

25.26m(82.87ft)

12.63m(41.43ft)

8~32mm(W)

150.77m(494.65ft)

60.31m(197.86ft)

30.15m(98.91ft)

15.08m(49.47ft)

8~32mm(T)

413.97m(1358.16ft)

165.59m(543.27ft)

82.79m(271.62ft)

41.40m(135.82ft)

Functions

Client Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE (plug-in required)/Google Chrome/Edge/Firefox/Safari

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, sensor detection, SD card error, SD card full, IP address conflict, cable disconnection

General Function

Watermark, IP address filtering, video mask, heartbeat, password protection, image distortion correction, corridor pattern

PoE

Yes , IEEE802.3af

IR Distance

70~ 100 m

Ingress Protection

IP67 & IK10

Others

Power Supply

AC24V/DC12V/PoE

Power Consumption

< 14W

Operating Environment

- 50 °C ~ 60 °C (-58°F~140°F); Humidity: less than 95 % (non-condensing)

Storage Environment

- 50 °C ~ 65 °C (-58°F~149°F); Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

411.9 × 155.3 ×188

Weight ( net )

Approx. 2.762KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
