Camera

Image Sensor

1 / 2.7 "CMOS

Image Size

2592 × 1944

Electronic Shutter

1 / 2 s ~ 1 / 100000 s

Iris Type

Fixed Iris

Min. Illumination

0.006 Lux@ F1.0, AGC ON; 0 Lux with LED ON, AGC ON

S/N Ratio

≥50dB

Lens

2.8 mm@F1.0, horizontal FoV: 97°; vertical FoV: 72°; diagonal FoV:128°

3.6 mm@F1.0, horizontal FoV: 78°; vertical FoV: 58°; diagonal FoV:101°

Focus

Fixed

Lens Mount

M12

Wide Dynamic Range

120dB

BLC

Yes

HLC

Yes

Defog

Yes

Digital NR

3D DNR

Angle Adjustment

Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360°


Video Compression

Main stream: H.265+ / H.265 / H.264+ / H.264

Sub stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

Third stream: H.265+ / H.265 / H.264+ / H.264 / MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

5MP (2592×1944 ), 4MP (2592×1520), 2K (2560×1440), 3MP(2304×1296 ),

1080P (1920×1080), 720P (1280×720 ), D1, CIF, 480×240

Main Stream

5MP/4MP/2K/3MP/1080P / 720P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Sub Stream

720P/D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Third Stream

D1/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps )

Bit Rate

64 Kbps ~ 8 Mbps

Bit Rate Type

VBR / CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast,Wide Dynamic, Sharpness, Image Flip, Image Mirror, NR, etc.

adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces

Network

RJ45

Video Output

No

Audio

1CH audio input

Storage

Built-in micro SD card slot; up to 256GB

Reset

Yes

Alarm

No

Intelligent Analytics (Smart Events)

Perimeter Protection

Line crossing, region entrance/exiting/intrusion (human/motor vehicle/ non-motor vehicle classification)

Statistics

Target counting by line/area, heat map

Exception Detection

Scene change, video blur and video cast detection

Face Detection

Face detection and face capture

Other Events

Abandoned/missing object detection, crowd density detection

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8mm

53.51m(175.55ft)

21.40m(70.20ft)

10.70m(35.10ft)

5.35m(17.55ft)

3.6mm

70.14m(230.11ft)

28.05m(92.02ft)

14.02m(45.99ft)

7.01m(22.99ft)

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE(plug-in required)/Google Chrome/Edge/Firefox/Safari

Online Connection

Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, HTTP POST, RTMP, QoS

Interface Protocol

ONVIF

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection, SD card error, SD card full

General Function

Watermark, IP address filtering, video mask, heartbeat, illegal login lock, corridor pattern

PoE

Yes , IEEE802.3af

White Light Range

20~30 m

Ingress Protection

IP67

Others

Power Supply

DC12V/PoE

Power Consumption

< 7W

Storage Conditions

- 30 °C ~ 65°C (-22°F~149°F), Humidity: less than 95 % (non-condensing)

Operating Conditions

- 30 °C ~ 60 °C (-22°F~140°F), Humidity: less than 95 % (non-condensing)

Dimensions ( mm )

217.8 × 80.5 × 80.3

Weight ( net )

Approx. 0.68KG

Installation

Ceiling mounting; Wall mounting

Certificate

CE, FCC

Environmental Protection

Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC and REACH(EC1907/2006)
