Camera

Image Sensor

1/3" Progressive Scan CMOS

Max. Resolution

2560 × 1440

Min. Illumination

0.008 lux@F2.1, AGC ON; 0 lux with IR ON

Shutter Speed

Auto

WDR

120dB

S/N Ratio

≥ 50dB

BLC

Yes

HLC

Yes

Digital NR

3D NR

Lens

Lens Type

Fixed focal lens, 2.1mm

Aperture

F2.1

FOV

H.FoV: 103°; V.FoV:70°; D.FoV:110°

Lens Mount

M12

DORI

DORI

D: 37 m, O: 15m, R: 7 m, I: 4 m

Illuminator　

Supplement Light Type

IR Light, 850nm

Supplement Light Range

Up to 10 m

Overexposure Control

Yes

Video & Audio　

Video Compression

Main stream: H.265+ / H.265/ H.264+ / H.264
Sub/Third stream: H.265+ / H.265/ H.264+ / H.264 MJPEG

H.264 Compression Standard

Baseline Profile/Main Profile/High Profile

Resolution

4MP (2560×1440 ), 3MP (2304×1296 ), 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 ×240

Main Stream

4MP/3MP/1080P/720P(60Hz: 1~30fps; 50Hz:1~25fps)

Sub Stream

720P/D1/CIF (60Hz: 1~30fps; 50Hz:1~25fps)

Third Stream

D1/480 ×240/CIF(60Hz: 1~30fps; 50Hz:1~25fps)

Bit Rate

64Kbps ~ 8Mbps

Bit Rate Type

VBR/CBR

Audio Compression

G711A / U

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR, etc. adjustable through client software or web browser

ROI

Each ROI to be configured separately

Interfaces　

Network

1 CH RJ45 10 M/100 M self-adaptive Ethernet port

Wi-Fi

Support 2.4G, 5G, built-in antenna

Audio

2CH built-in MIC (supports audio noise reduction); 1 CH built-in Speaker; 1CH audio input; 1CH audio output

Alarm

1CH alarm input; 1CH alarm output

RS-485

Yes, half-duplex

Storage

Built-in micro SD card slot, up to 256GB

Reset

Yes

Functions

Remote Monitoring

Web Browser/TVT NVMS2.0/NVR/mobile APP

Web Browser

IE11(plug-in required)/Chrome 89.0+/Edge 89.0+/Firefox 87.0+/Safari 14.0+

Online Connection

Support simultaneous monitoring for up to 3 users;
Support multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, SNMP, PPPoE, DDNS, 802.1x, SMTP, FTP, UPnP, HTTPS, HTTP, QoS, HTTP POST

Interface Protocol

ONVIF, SDK

People Counting

Counts people entering and exiting separately and supports daily/monthly/annual report
Supports children counting; supports target height filtering; supports human head detection algorithm

Smart Alarm

Motion detection, SD card error, SD card full, video exception detection (scene change, video blur and video cast
detection),network disconnection, reverse entering detection, abnormal number of people detection

Linkage

Upload to memory card/FTP, notify surveillance center, audible warning, trigger recording, trigger capture, send email

General function

Watermark, heartbeat

Security

Video encryption, firmware encryption, HTTPs encryption, configuration encryption, illegal login lock, IP address
filtering,802.1x authentication, basic and digest authentication for HTTP

Others

Power

DC12V/PoE

Power Consumption

< 9W

Working Environment

-30℃ to 45 ℃ (-22 °F to 113 °F). Humidity 95% or less (non-condensing)

Installation Height

2.1m~6m

Weight (net)

Approx.0.563kg

Protection

Protection

IP66

Certificate

CE, FCC

Environmental Protection

RoHS2.0，REACH，WEEE，directive94/62/EC
