Decoding & Display
1CH 4K HDMITM input
2 HDMITM outputs, HDMITM1supports 4K/1080P HD output; HDMITM2 supports 1080P HD output
1 VGA output and 1 BNC output
2CH 8MP/5MP real-time or 8CH 4MP/3MP/1080P/720P real-time or 32 CH D1 real-time
H.265 HP/MP/BP and H.264 HP/MP/BP encoding format
Support PS, RTP,TS,ES package format（in platform running mode）
G.711A/G.711U
1 CH audio input; 1CH audio output
Stream Mode
A&V streams can be directly acquired from TVT IPC/DVR/NVR by SDK private protocol
A&V streams can be acquired from NVMS platform or encoding devices by RTSP/RTP protocol
A&V streams can be acquired from IPC by ONVIF protocol
Decoding Control
Support live view and playback decoding
1/4/9/16 screen display mode
Splicing, picture-in-picture, roaming
View cameras or camera groups in sequence
Support infinite splicing display, typical splicing mode: 2×2/3×3/4×4/6×4 etc.
Support a maximum of 24 CH output; up to 12 decoding cards inserted
Device Management
Support multi-level device control（Master-slave mode）
A maximum of 64 decoders can be manageable
Access
Provide HTTP API protocol to third-party platform
Support platform running mode and device running mode
Operation and Maintenance
Support device search
Support WEB client access, configuration and management
Support time zone, time and date settings
Support IP address, subnet mask and gateway settings
Support data port and HTTP port settings
Support data backup and restoration
Support remote reboot and one-button reset
Support online and U-disk upgrade
Support dual gigabit Ethernet ports, load balancing
Modular and hot pluggable designs are convenient to expand and maintain and unaffected to other board card when one board card is damaged
Pulsuz Çatdırılma 100 AZN yuxarı bütün sifarişlərə şamil olunur
Bütün məhsullara 100% zəmanət verilir
1gün ərzində məhsulları geri qaytarma edə bilərsiz
Covid-19 Məlumatı: Çatdırmağa davam edirik.
System | CPU | Intel® Pentium 4405U |
| Memory | DDR4，8GB | |
| Graphics Card | Integrated Graphics，Intel® HD Graphics 510 | |
| Operation System | Linux | |
Software | Software | NVMS standard (custom) |
| Decoding Capability | 4CH 8MP or 6CH 5MP or 8CH 4MP or 14CH 1080P or 33CH 720P or 36CH D1 (orlower) | |
| Max. Number of Channel Access | 256CH | |
| Max. Number of Device Access | 64 NVRs/FR Servers | |
| AI Capability | Support the integrated management of face detection IPCs, face match servers, face recognition terminals, face match NVRs，ANPR cameras | |
| Support face detection, image search by face image, track playback, allow list and block list alarm as well as stranger alarm | ||
| Support face attendance, face greeting, people counting, parking lot management | ||
| Access | Support local GUI access; external mouse, keyboard and monitor; multi-monitor display | |
| Protocol | Private protocol, SDK, ONVIF, RTSP, | |
| Live View | Support multi-screen display mode; support customized | |
| screen display mode, corridor mode, channel group auto-switch, stream self-adaption, manual record and snapshot | ||
| Record Playback | Support search record by time period, time slice, time and tag; support synchronous or asynchronous playback; support record backup | |
| Alarm Linkage | Support triggering message popup, audio, live view window, recording with tag, decoding on TV Wall | |
| PTZ Control | zoom in, zoom out, preset, cruise, 3D control | |
HDD | System HDD | mSATA SSD 128GB |
| Data HDD | NO | |
Video &Audio | HDMITM Output | 1CH HDMITM @ 4K |
| VGA Output | 1 VGA @ 1080P | |
| Audio Output | 1CH Line out | |
| Two-way Audio | 1CH MIC IN | |
External Interface | Ethernet Interface | 1 个，RJ45 10M/100M/1000M self-adaptive Ethernet port |
| USB Interface | 6 USB ports: USB 3.0x2（front panel），USB 2.0x2（rear panel）， USB 3.0x2（rear panel） | |
| Wi-Fi | 1xM.2 2230（optional） | |
Others | Power | DC 12V/3A |
| Power Consumption | ≤36W | |
| Working Temperature | -5℃--＋45℃ | |
| Storing Temperature | -20℃--＋70℃ | |
| Working Humidity | 10%--95% | |
| Dimensions | 154mm(W)×120mm(H)×30mm(D) | |
| Weight | ≤0.47Kg |
